Hardware Features

• Axial flow agitation
• Automated parts lift with adjustable build tray fixture
• Catch tray
• Detergent Pump
• Enclosed safety-interlocked process area
• LED chamber lighting with RGB workflow status indicator
• Mounting provisions for ventilation
• Casters for easy installation
• Stainless steel process tank
• Additional fixtures available for purchase

Size and Weight

• Envelope: 14” L x 14” W x 15” H (36 cm x 36 cm x 38 cm)
• Machine footprint: 32” L x 25” W x 67”H (82 cm x 64 cm x 170 cm)
• Approximate Weight: 325 lbs (147 kg) empty, 525 lbs (238 kg) full

Detergent

• Capacity: 24 Gallons (91 Liters)
• Resin Materials: PLM-403-SUB and AUX-400-RINSE (Implement an IPA-free resin removal workflow with AUX-400-RINSE as the final rinse step. **Note: rinse step is to be performed in separate container, not to be used in PostProcess hardware)

Electrical

• North America:
• Power: 120V, 60Hz, Connector: NEMA 5-15P
• Axial agitation; includes heater
• Europe
• Power: 230V, 50Hz, Connector: CEE 7 / 7
• Axial agitation; includes heater

Safety Features

• Emergency stop
• Safety enclosure with door sensor
• Redundant over-temperature safety system
• CE, UL/CSE certified.
